Stripping bender KMS HPZ 10 (10T)
Stripping bender KMS HPZ 10 (10T)
Contact us for price
or
Call +31 655 062 286
Description
New strip bender with a capacity of 10 Ton.
Standard features include:
Full steel frame.
Stroke adjustment by digital readout.
Step by step or automatic cycle.
Induction hardened and ground tools and pins.
Foot pedal for machine operation.
1 set of tooling (V-groove 60, Knife R5).
English language user manual.
Cut/punch/targeting and bending tools are optional:
Click here for info Optional pipe bender.
Machine also available as 20 / 30 / 40 / 50 Ton version
Specifications
| Manufacturer | KMS |
| Model | HPZ 10 |
| Condition | New |
| Capacity | 10 Tons |
| Soort | Strip bender |
| Standard tool height | 150 mm |
| Max. bending capacity st-37 | ± 150x8 mm (V60) |
| Mains voltage | 400V |
| Motor | 1.1 kW |
| Table dimensions | 450 x 900 mm |
| Exterior dimensions machine | 450 x 900 x 1100 mm (lxwxh) |
| Machine weight | 370 kg |
